Forged Steel Y Globe Valve, ASTM A182 F316, 3/4 IN, 2500 LB

Aug 04, 2024

Forged Steel Y Globe Valve, ASME B16.34, ASTM A182 F316, 3/4 Inch, ANSI 2500, OS&Y, Butt Weld End.

Valve Description:	1852051 Globe Valve
Design Standard:	ASME B16.34, API 602
Structure:	Bonnetless, Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet
Nominal Size:	3/4 Inch
Nominal Class:	Class 2500 LB, PN420
Bore Type:	Reduced
Face to Face:	MFG'S
Trim Material:	ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Operation:	Handwheel
Test and Inspection:	API 598
Applications:	Oil and Gas Industry, Water Treatment Plants, Power Generation, Chemical Processing.
Benefits:	Reduced Pressure Drop, Less Turbulence, Improved Flow Control, Space-Efficient.
Body Material:	ASTM A182 F316, ASTM A182 F11, ASTM A105N, ASTM A182 F22, ASTM A182 F91
End Connection:	BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)

Key Features:

1. Rising Stem with Handwheel for Precision Control
2. Compact, Robust Construction for High-Temperature and High-Pressure Environments
3. Outside Screw & Yoke (OS&Y) for Enhanced Operation
4. Y-Pattern Design for Efficient Flow Management
5. Live Load Packing for Superior Sealing
6. Backseat for Additional Leak Prevention
7. Options: Swivel, Plug, or Needle Disc

Product Portfolio:

Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
