Bonnetless Y-pattern Globe Valve, A182 F91, 1-1/2 IN, 4500 LB

1-1/2 Inch Y-pattren Globe Valve, ASME B16.34, DN40, CL 4500 LB, A182 F91 Body, BW Ends.


Valve Description:

1852063 Globe Valve
Design Standard: ASME B16.34, API 602
Body Material: ASTM A182 F91, ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A105N
Nominal Size: 1-1/2 Inch, DN40
Nominal Class: Class 4500 LB
Structure: Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet, Bonnetless
Bore Type: Reduced Bore
Face to Face: MFG'S
Operation: Handwheel
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Applications: Chemical Processing, HVAC Systems, Oil and Gas Industry.

Key Features:

1. Rising Stem with Handwheel: For precise and easy operation.
2. Interchangeable Discs: Options include swivel, plug, or needle disc for versatile applications.
3. Y-Pattern Design: Optimizes flow management and reduces pressure drop.
4. OS&Y Configuration: Outside Screw & Yoke design for reliable performance.
5. Live Load Packing: Ensures superior sealing and ease of maintenance.
6. Backseat Feature: Provides additional safety and protection.
7. Compact and Durable: Engineered to withstand high-temperature and high-pressure conditions.


Product Portfolio:

Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2-2 Inch (DN15-DN50)
Pressure Range: 800-4500 LB
Operation: Manual or Actuated
Working Temperature: -29°C to +525°C
End Connection: BW/SW/NPT
