ASTM A890 4A Gate Valve, 3 Inch, 150 LB, API 600, RF

Name: ASTM A890 4A Gate Valve, 3 Inch, 150 LB, API 600, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Shop high-quality Duplex Stainless Steel 4A Gate Valve fabricated to ASTM A890 4A specifications. This gate valve is designed for optimal performance, featuring a 3-inch size, Class 150 LB rating, and API 600 compliance. With a DN80 and PN20 configuration, it ensures reliable operation. The valve boasts a bolted bonnet design and offers the flexibility of RF or BW ends. Rigorously tested to meet API 598 standards, this Duplex Stainless Steel 4A Gate Valve is a top choice for industrial applications.

Request a quote

Detail Information

Gate valve, carbon steel, bolted bonnet, NPS 3, 150 LB, ASTM A890 4A, RF.

Valve description:
Gate valve, bolted bonnet, Raised flange.
Design: API 600.
Body: ASTM A890 Grade 4A
Nominal size: 3 Inch.
Nominal class: 150 LB.
End Connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Duplex Stainless Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Gate valve.
Nominal diameter	1/2 Inch - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Duplex steel.
Design standard	API 600.
Face to face	ASME B16.10.
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
Special test	Impact test.
