Weld Bonnet Piston Check Valve, ASTM A182 F22, 3/4 IN, 1500 LB

Name: Weld Bonnet Piston Check Valve, ASTM A182 F22, 3/4 IN, 1500 LB
SKU: VF-231214-CV-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a reliable manufacturer, we take pride in presenting our Weld Bonnet Piston Check Valve. Crafted from ASTM A182 F22 alloy, this valve stands as a testament to durability and high performance. With a 3/4-inch size and a robust Class 1500 LB rating, it excels in fluid control applications. The NO.5 Trim ensures precision and efficiency, enhancing its overall reliability.

Request a quote

Detail Information

Standard: API 602
Material: ASTM A182 F22
Trim: NO.5
Size: 3/4 Inch, DN20
Class Rate: 1500 LB, PN250
Ends: NPT, NPT * SW, SW
Operating: Hand Wheel
Testing: API 598
Face to face: ASME B16.10
Flanges: ASME B16.5

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
