High-precision Laser Particle Sensor, Anti-interference
Key Specifications / Features
Laser Particle Sensor Provider: Laser-based Particle Sensors, Anti-interference, High Precision, -15-60℃ Working Temperature, -30-70℃ Storage Temperature.
Request a quote
Detail Information
Features
·Based on the principle of laser scattering
·Small design
·Low power consumption
·High anti-interference capability
·Minimum particle resolution of 0.3μm in size
·Superior sensitivity and consistency
·Real-time detection output
·Functional expansion: add formaldehyde sensors
·Installation size and interface are compatible with infrared sensors
Application Environments
·Air Purifier
·Fresh Air System
·Air Conditioner
·Car Air Purifier
·Air Quality Detector
·Environmental Monitoring
·Handheld Air Quality Detector
Specification Parameters
Measurement Type: PM2.5
Measurement Range: 0-1000μg/m3
Measurement Consistency: ＞100μg/m3: ±10%; ＜100μg/m3: ±10μg/m3
Measurement Accuracy (Reference Standard: TSI 8530): ＞100μg/m3: ±10%; ＜100μg/m3: ±10μg/m3
Data Interface: UART 9600 bps
Inlet and Outlet: Front
Power Supply: DC 5±0.5V
Working Condition: Temp: -15-60℃; Humidity: 0-90% RH
Storage Condition: Temp: -30-70℃; Humidity: 0-90% RH
Weight: 24g
Size: 59mm x 45mm x 14mm
MTTF: ≥30000H (Intermittent Mode: Intermittent Operation)
Product Classification
·Based on the principle of laser scattering
·Small design
·Low power consumption
·High anti-interference capability
·Minimum particle resolution of 0.3μm in size
·Superior sensitivity and consistency
·Real-time detection output
·Functional expansion: add formaldehyde sensors
·Installation size and interface are compatible with infrared sensors
Application Environments
·Air Purifier
·Fresh Air System
·Air Conditioner
·Car Air Purifier
·Air Quality Detector
·Environmental Monitoring
·Handheld Air Quality Detector
Specification Parameters
Measurement Type: PM2.5
Measurement Range: 0-1000μg/m3
Measurement Consistency: ＞100μg/m3: ±10%; ＜100μg/m3: ±10μg/m3
Measurement Accuracy (Reference Standard: TSI 8530): ＞100μg/m3: ±10%; ＜100μg/m3: ±10μg/m3
Data Interface: UART 9600 bps
Inlet and Outlet: Front
Power Supply: DC 5±0.5V
Working Condition: Temp: -15-60℃; Humidity: 0-90% RH
Storage Condition: Temp: -30-70℃; Humidity: 0-90% RH
Weight: 24g
Size: 59mm x 45mm x 14mm
MTTF: ≥30000H (Intermittent Mode: Intermittent Operation)
Product Classification
| PN | Range (μg/m3) | Product Type | Packing Specification | L*W*H (mm) |
| PS5312 | 0-1000 | PM2.5 | 60 pcs/layer, 5 layers/ctn | 510*295*295 |
