Single-Seated Control Valve, A351 CF8, 1/2-2 IN, 150-2500 LB
Key Specifications / Features
The Single-Seated Angle Control Valve Plant in China is meticulously crafted with high-quality materials such as ASTM A351 CF8 and ASTM A351 CF8M, ensuring durability and reliability. Available in sizes ranging from 1/2 to 2 inches and with pressure ratings from Class 150 to 2500 LB, these valves are designed to meet a variety of industrial needs. They come with multiple end connection options including flanged, socket weld, and butt weld, providing flexibility for installation and integration into different systems.
Detail Information
Performance Characteristics:
Suitable for high-pressure and high-temperature environments, including handling slurry polymer crystals and fluids.
Features a simple structure and easy maintenance, making it a cost-effective control valve.
Designed primarily for small valve sizes due to its unbalanced trim structure, with a maximum size limit of DN50.
Body Size: 1/2 Inch, 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch, 2 Inch
Body Rating: Class 150 LB, 300 LB, 600 LB, 900 LB, 1500 LB, 2500 LB
Fluid Temperature: -196 - +550℃
Connections: Flanges(FF,RF,RJ,RTJ), Socket Weld, Butt Weld(SW,BW)
Body Materials: ASTM A216 WCB, ASTM A217 WC6, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M
Plug Materials: SS 316, SS 316 + Stellite, SS 316 + RTFE, etc.
Seat Leakage: ANSI Class IV(Cv×0.01%)
Rangeability: 30:1 - 10:1
Flow Characteristics: Linear, EQ%
Suitable for high-pressure and high-temperature environments, including handling slurry polymer crystals and fluids.
Features a simple structure and easy maintenance, making it a cost-effective control valve.
Designed primarily for small valve sizes due to its unbalanced trim structure, with a maximum size limit of DN50.
Body Size: 1/2 Inch, 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch, 2 Inch
Body Rating: Class 150 LB, 300 LB, 600 LB, 900 LB, 1500 LB, 2500 LB
Fluid Temperature: -196 - +550℃
Connections: Flanges(FF,RF,RJ,RTJ), Socket Weld, Butt Weld(SW,BW)
Body Materials: ASTM A216 WCB, ASTM A217 WC6, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M
Plug Materials: SS 316, SS 316 + Stellite, SS 316 + RTFE, etc.
Seat Leakage: ANSI Class IV(Cv×0.01%)
Rangeability: 30:1 - 10:1
Flow Characteristics: Linear, EQ%
