SS 304 Magnetic Drive Pump, DN10-DN100, 5-50 M Head, 120 L/min

Name: SS 304 Magnetic Drive Pump, DN10-DN100, 5-50 M Head, 120 L/min
SKU: KV-20250125-MDP-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The SS 304 Magnetic Drive Pump is designed for efficient and reliable fluid transfer in various industrial applications. Available in sizes ranging from DN10 to DN100, the pump features a body made from SS 316 or SS 316L, ensuring excellent corrosion resistance and durability. With a delivery head range from 5 to 50 meters and a flow rate of 12-60 m³/h, it provides reliable performance across a wide range of flow requirements. The pump also offers a capacity of 120 L/min.

Request a quote

Detail Information

Product Name: Self-Priming Stainless Steel Magnetic Drive Pump
Size: DN10-DN100 mm
Pump Housing Material: Stainless Steel SS 304, SS 316, SS 316L
Liquid Temperature: ≤ 80°C (customizable up to 200°C)
Delivery Head: 5-50 M
Flow Rate: 12-60 m³/h
Motor Power: 0.37-15 kW
Standard Capacity: 120 L/min
Other: Voltage options available per customer requirements

The Stainless Steel Magnetic Drive Pump utilizes magnetic couplings as the main working principle in its centrifugal pump design. The pump body and fluid-contacting parts are made from stainless steel, offering excellent corrosion resistance. Key features include full sealing with no leakage, advanced design, compact structure, low noise, stable operation, and easy maintenance. It is known for its reasonable design, durability, and aesthetic appearance.

Applications

This oil pump is suitable for pumping acid, alkali, oil, rare and precious liquid, plating solution, volatile liquid, and circulating water equipment in chemical, pharmaceutical, petroleum, electroplating, food, film photographic printing, scientific research institutions, national defense industry and other units. It is especially suitable for flammable, explosive, corrosive, volatile liquid pumping.
