Mechanical Diaphragm Metering Pump, 50 Hz, 25-500 L/H, 1.5 m

Name: Mechanical Diaphragm Metering Pump, 50 Hz, 25-500 L/H, 1.5 m
SKU: KV-20250125-MP-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Mechanical Diaphragm Metering Pump features a capacity range from 25 L/H to 500 L/H at 50 Hz, offering accurate and reliable performance. Operating at pressures between 5 and 10 bar, this pump features a suction lift of up to 1.5 meters. Constructed from durable materials such as PVC, SUS 304, SUS 316, and Teflon, it offers excellent chemical resistance and longevity.

Request a quote

Detail Information

Product Name: Mechanical Diaphragm Dosing Metering Pump
Capacity Range: 25 L/h to 500 L/h (at 50 Hz)
Pressure Range: 5-10 bar
Suction Lift: 1.5 m
Stroke Adjustment: 0 - 100%
Accuracy: ±2% of set point
Measuring Pump Head: PVC, SUS304, SUS316, Teflon
Measuring Valve: PVC, SUS 304, SUS 316, Teflon
Valve Materials: Silicon Dioxide, SUS304, SUS316, Ceramics
Sealing Materials: Teflon, PVC
Motor: Standard Two-phase, Three-phase, or Explosion-proof Motor
Power: 0.25 kW, 0.37 kW, 0.55 kW
Protection Level: IP54
Environmental Temperature: -30°C to 90°C
Max Processing Temperature: Up to 70°C (158°F)

The Mechanical Diaphragm Metering Pump is a heavy-duty, high-performance pump designed for chemical dosing. It features a double-diaphragm design for sensitive liquid dosing and a reinforced plate to protect the diaphragm, increasing its lifespan. The stroke length and speed are adjustable to alter capacity. Suitable for dosing chemicals like aluminum sulfate, polymers, alkalis, sodium hydroxide, acids, anti-scaling agents, and chlorine. Widely used in waste treatment, industrial chemical processes, agriculture, and more.
