SS 304 Angle Needle Valve, 1/2 Inch, DN15, PN320, Male NPT

Name: SS 304 Angle Needle Valve, 1/2 Inch, DN15, PN320, Male NPT
SKU: KV-20250217-NV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The SS 304 Angle Needle Valve features a stainless steel body for corrosion resistance and durability. With a 1/2-inch (DN15) size and a pressure rating of PN320 (Class 2500 LB), it is designed for high-pressure applications. The valve comes with male NPT ends, ensuring a secure and leak-proof connection, making it ideal for precise flow control in demanding industrial environments.

Request a quote

Detail Information

Product Name: Angle Type Needle Valve
Body Material: Stainless Steel SS 304
Size: 1/2 Inch, DN15
Pressure: PN320, Class 2500 LB
End Connection: Male NPT
Operation: Manual

The Angle Type External Thread Needle Valve is known for its long service life, high temperature resistance, and vertical valve tip movement, which eliminates rotation. It features a sleek, compact design with a lightweight feel for easy operation. Made from high-temperature and high-pressure stainless steel, this needle valve is a crucial component in instrument measurement pipeline systems. It offers advantages such as easy installation, tight connections, excellent fire prevention, explosion-proof properties, high pressure resistance, and strong sealing performance. Ideal for use in power plants, refineries, chemical plants, and instrument measurement pipelines, it serves as a flow switch for high-pressure gas and liquid systems. The valve's reliable quality can be tailored to meet specific user requirements with non-standard designs and special material options.

Technical Specifications

Type: Angle
Usage: Cut-off
Nominal Diameter: DN6-DN100 mm, 1/8-4 Inch
Nominal Pressure: 1.0 - 42.0 MPa, PN10-PN420
Main Materials: SS 304, SS 316
Connection Method: External Threaded/Male Threaded
Working Temperature: -54°C to 316°C (-65°F to 600°F)

Product Performance

» Low Torque Design: Ensures the valve is lightweight and easy to operate.
» Traceable Materials: All raw materials used in the main components are traceable for quality assurance.
» Leak-proof Sealing: PTFE or flexible graphite sealing pressure device ensures no leakage during valve stem operation.
» Compact Structure: The valve has a compact design, attractive appearance, and flexible application, offering tight connections and reliable sealing performance.
» Easy Installation & Disassembly: Facilitates quick installation and disassembly with secure connections, making it beneficial for fire prevention, explosion-proof applications, high pressure resistance, and excellent sealing performance.
