Self-priming Sewage Pump, DN25-DN300, 12-60m Head, 2.2-55 KW

Product Name: Self-priming Non-clogging Sewage Pump
Product Type: Self-priming Sewage Pump
Diameter: DN25-DN300
Self-priming Height: 4.5-6 m
Flow: 5-800 m³/h
Head: 12-60 m
Speed: 1450-2900 r/min
Motor Power: 2.2-55 KW
Working Temperature: -20°C to 100°C
Other: The voltage is optional as required by the customer

Self-priming Sewage Pump Description

The ZW Self-Priming Non-Clogging Sewage Pump combines self-priming and non-clogging capabilities in one unit. Featuring a unique axial reflux outer recirculation design through the pump body and impeller passage, this pump operates without the need for a bottom valve or irrigation water. It can handle liquids containing large particles and solid impurities up to five times the outlet diameter, with a self-priming height of up to 5 meters. It is ideal for replacing all types of submersible and liquid-type sewage pumps. Widely used in industries such as chemical, electrical, mining, paper, textile, printing and dyeing, environmental protection, food, municipal sewage, and more, the ZW sewage pump excels in pumping solid particles, fibers, pulp, and mixed suspensions.

Self-priming Sewage Pump Applications

» Chemical and Pharmaceutical: Transport of liquids containing chemicals and other solids

» Mining: Efficient handling of sewage and slurry

» Paper and Pulp: Pumping fibers, slurry, and other solid-laden liquids

» Textile and Printing/Dyeing: Pumping viscous and contaminated liquids

» Environmental Protection: Managing sewage in municipal wastewater treatment systems

» Food Industry: Transporting liquids with solid particles

» Ponds and Aquaculture: Used in wastewater and sludge management

» Municipal Sewage: Handling large volumes of waste in urban infrastructure

Self-priming Sewage Pump Key Features

» Self-Priming Capacity: High self-priming performance with a height of up to 5 meters

» Non-Clogging Design: Unique impeller design prevents clogging, ensuring consistent performance

» Energy Efficiency: High-efficiency hydraulic model, improving self-priming performance by 3 to 5% compared to average pumps

» Versatile: Capable of handling large solid particles (up to 60% of pump bore diameter) and fibers (up to 5 times the diameter)

» Easy Maintenance: Simple structure allows for quick and easy maintenance, minimizing downtime

Self-priming Sewage Pump Working Conditions

» Ambient Temperature: ≤ 24°C

» Medium Temperature: ≤ 60°C

» Medium pH: 6-9 for iron pumps; 1-14 for stainless steel pumps

» Particle Size: Maximum particle diameter of 60% of the pump bore diameter, fiber length up to 5 times the diameter

» Medium Composition: The total weight of impurities in the medium should not exceed 15% of the total medium weight; medium density should not exceed 1240 kg/m³
