ASTM B148 C95800 Globe Valve, ASME B16.34, 3 Inch, CL150, RF

Name: ASTM B148 C95800 Globe Valve, ASME B16.34, 3 Inch, CL150, RF
SKU: KV-20250218-CSGLV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The China ASTM B148 C95800 Globe Valve is a high-quality valve designed in accordance with ASME B16.34 standards. It features an aluminum bronze body, ensuring durability and corrosion resistance. The valve has a 3-inch diameter (DN80) and is rated for Class 150 LB pressure, equivalent to PN20. It is equipped with RF (raised face) flanged ends for secure and reliable connections.

Request a quote

Detail Information

Product Name: ASTM B148 C95800 Globe Valve
Design Standard: ASME B16.34
Body Material: ASTM B148 C95800
Size: 3 Inch, DN80
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Handwheel

Cast Steel Globe Valves are designed and manufactured to achieve a VOC leakage of less than 100 ppm (parts per million). Extensive baseline laboratory testing, including both static and cycle testing, has been conducted to establish the critical design parameters necessary for low-emission sealing in the stem packing and bonnet gasket areas. We have developed an in-house testing procedure that is periodically performed to ensure that the standard product design and manufacturing consistently result in less than 100 ppm VOC leakage prior to shipment.

Technical Specification

» Nominal Diameter: NPS 2-24 Inch (DN50-DN600)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: ASTM B148 C95400, C95500, C95800, ASTM B150 C63000, C63200
» End Connections: Flanged (FF, RF) to international standards
» Operation: Hand Wheel, Bevel Gear, Electric, Pneumatic
» Applications: Electric Power, Petroleum Refining, Petrochemical Engineering, Offshore Oil, Tap Water Engineering in Urban Construction, Chemical Engineering
» Temperature Range: -29°C to 595°C
» Medium: for sea water, offshore, marine
» Design and Manufacture Standards: ASME B16.34, BS 1873, DIN 3356
» Face to Face (End to End): ANSI B16.10, EN 558 Series
» Flanged Connections: ANSI B16.5, EN 1092 Series
» Butt Welded Ends: ANSI B16.25
» Test and Inspection Standards: API 598, ISO 5208, EN 12266-1

Product Features

» OS&Y, Bolted Bonnet, Rising Stem – Ensures durability and ease of maintenance.
» Short Stroke – Enables quick and efficient opening and closing.
» Internal Bypass for Large Sizes & High Pressure – Features a relief cone for pressure equalization.
» Disc Sealing Options – Available with flat sealing or a throttle cone for flow regulation.
» Body Seat Variants – Can be either threaded or welded for secure sealing.
» OS&Y (Outside Stem and Yoke) – Enhances visibility and operational reliability.
» Optional Features – Locking device, stem extension, and direct mounting to ISO 5211.
» Reduced Port Design – Optimized for controlled flow applications.
