ASTM A105N Angle Globe Valves, API 602, 1.5 IN, CL2500, PSB

The ASTM A105N Angle Globe Valves Supplier offers high-performance angle globe valves designed for demanding industrial applications. These valves feature a forged carbon steel body, ensuring strength and durability. They comply with API 602 standards and have a 1-1/2 inch (DN40) size with a Class 2500 LB pressure rating and a PN420 nominal pressure. The valves are equipped with a pressure seal bonnet, which enhances sealing performance at high pressures. They also feature socket welded ends for secure and reliable connections.

Product Name: Pressure Seal Bonnet Angle Globe Valves
Type: Angle Globe Valve
Design Standard: API 602
Body Material: ASTM A105N
Size: 1-1/2 Inch, DN40
Pressure: Class 2500 LB, PN420
End Connection: SW
Operation: Manual
Medium: Water, Oil, Gas, etc
Temperature Range: -29°C to 595°C

Pressure Seal Globe Valves are designed and manufactured to meet international standards such as API 602, ASME B16.34, DIN 3202, or their equivalents. These valves feature a compact yet robust design suitable for high pressure and high-temperature applications. The solid CoCr alloy wedge (optional) ensures low friction and long service life. Packing rings are precompressed to 4000 psi, providing a high-integrity seal. For welded bonnet valves, the bonnet is threaded and torqued to a precise engineered value, and the body-bonnet joint is strength-welded for double protection against leakage. The fully guided wedge reduces wear on seating surfaces. Optional designs include double packing, leak-off connections, live-loading, and packing blowout features for easy removal of old packing.

Technical Specifications

» Type: Pressure Seal Globe Valve
» Size Range: 1/2-2 Inch (Forged items)
» Temperature Range: -29°C to 595°C
» Design Pressure: CL900 to CL2500 (PN160 to PN420)
» Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, and others
» Trim Materials: 13% Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L, and special alloys
» End Connections: Socket Weld (SW), Butt Weld (BW), Ring Type Joint (RTJ) Flange
» Design & Manufacturing Standards: ASME B16.34, API 602
» Face-to-Face Dimensions: ANSI B16.10
» Flanged Connections: ANSI B16.5
» Testing & Inspection: API 598, API 6D
» Butt Weld Ends: ANSI B16.5
» Socket Weld Ends: ASME B16.11

Product Features

» Forged steel materials offer excellent corrosion resistance, making these valves suitable for a variety of corrosive media and extending valve service life.
» Compact design with smaller volume and reduced space requirements makes these valves easy to install and ideal for applications with limited space.
