ASTM A234 WP91 Elbow Fittings, ID419, Thickness 80mm
Model Number: DW PE-4
Key Specifications / Features
ASTM A234 WP91 Elbow Fittings Manufacturer in China Duwa Piping Produces ASTM A234 WP91 Pipe Elbow, ANSI B16.9, ID419, Thickness 80, 90 Degree.
Detail Information
Type: 90 Degree Elbow.
Material: ASTM A234 WP91.
Size: 419 LR.
Degree: 90°.
Wall Thickness: 80mm
Ends: BW.
Standard: ANSI B16.9.
ASTM A234 WP91 Chemical Composition and Mechanical Properties:
Material: ASTM A234 WP91.
Size: 419 LR.
Degree: 90°.
Wall Thickness: 80mm
Ends: BW.
Standard: ANSI B16.9.
ASTM A234 WP91 Chemical Composition and Mechanical Properties:
| Chemical Composition Content % | |||||||
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A234 WP91 | 0.08-0.12 | 0.3-0.6 | 0.2-0.5 | ≤0.02 | ≤0.015 | 8-9.5 | 0.85-1.05 |
| Mechanical Properties | |||
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A234 WP91 | ≥590 | ≥415 | ≥20 |
