Lubricated Plug Control Valve, 150-900 LB, 1/2-24 Inch

Name: Lubricated Plug Control Valve, 150-900 LB, 1/2-24 Inch
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our Lubricated Plug Control Valves, essential quarter-turn mechanical valves utilized across diverse industrial sectors, particularly in oil and gas facilities. These valves derive their name from the sealing mechanism, which relies on grease between two metal surfaces. Designed for seamless compatibility, the plug surface and body inner surface materials ensure optimal performance. Enjoy the convenience of automatic actuator selection and default emergency sealing fittings. Features include a blow-out-proof stem for safety and an optional locking device for added security. Experience reliable operation and ease of maintenance with our lubricated plug valves.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Lubricated Plug Control Valve
Design Standard: ASME B16.34, API 6D, ISO 14313
Size Range: 1/2 Inch - 24 Inch, DN15-DN600
Pressure Rating: Class 150 LB - 900 LB, PN20-PN150
End Connection: RF (Raised Face), RTJ (Ring Type Joint), BW (Butt Weld)
End Connection Standard: ASME B16.10
Bore: Full Bore, Reduced Bore
Pattern Type: Short, Regular, Venturi
Operator: Lever, Gear, Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Standard, High
Fire Safe Standard: API 607, ISO 10497, API 6FA
Face to Face Standard:ASME B16.10
Test Standard: API 6D, API 598
Leakage Class: FCI 70-2 Class IV

Features:
Plug surface and body inner surface materials are compatible with each other.
The actuator selection is automatic.
Emergency sealing fittings are default.
Blow-out-proof stem.
Locking device is optional.
