Double Trunnion Ball Control Valve, API 6D, 2-36 Inch
Key Specifications / Features
Introducing our Double Trunnion Ball Control Valve for the industry, featuring a bolted design and gear actuator, compliant with ASME B16.34 and API 6D standards. Crafted from carbon steel, available in sizes ranging from 2 to 36 inches, and pressure ratings from Class 150 to 1500 LB, with RF and RTJ ends. Enjoy the benefits of smaller actuators thanks to low torque requirements, along with automated actuator selection for added convenience. Fixed lifting lugs ensure easy handling, while maintenance is simplified. Emergency sealing fittings are included, seats are renewable, and you can opt for metal or soft seats based on your preferences. Additional features include a blow-out-proof stem for safety, optional locking device for security, and instrumentation valves for draining the body cavity.
Request a quote
Detail Information
SPECIFICATIONS
Product Name: Double Trunnion Ball Control Valve
Design Standard: ASME B16.34, API 6D, ISO 14313, ISO 17292
Valve Type: Trunnion
Size Range: 2 Inch - 36 Inch, DN50-DN900
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
End Connection: RF (Raised Face), RTJ (Ring Type Joint)
Bore: Full Bore, Reduced Bore
Operator: Lever, Gear, Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Low, Standard, High
Leakage Class: API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Test Standard: API 6D, API 598, ISO 14313
Fire Safe Standard: API 607, ISO 10497, API 6FA
Features:
Smaller actuators can be chosen due to their low torque requirements.
Actuator selection is automated for added convenience.
Valve includes fixed lifting lugs for easy handling.
Maintenance is straightforward.
Emergency sealing fittings come as standard.
Seats are renewable for prolonged use.
Choose between metal and soft seats based on your needs.
Features a blow-out-proof stem for added safety.
Optional locking device enhances security.
Instrumentation valves are provided to drain the body cavity.
Product Name: Double Trunnion Ball Control Valve
Design Standard: ASME B16.34, API 6D, ISO 14313, ISO 17292
Valve Type: Trunnion
Size Range: 2 Inch - 36 Inch, DN50-DN900
Pressure Rating: Class 150 LB - 1500 LB, PN20-PN250
End Connection: RF (Raised Face), RTJ (Ring Type Joint)
Bore: Full Bore, Reduced Bore
Operator: Lever, Gear, Actuator
Material: Carbon Steel, Stainless Steel, Duplex, Alloy Steel
Operating Temperature: Low, Standard, High
Leakage Class: API 598, ANSI FC70-2, ISO 5208
Face to Face Standard: ASME B16.10
End Connection Standard: ASME B16.5, ASME B16.25, DIN EN 1092-1
Test Standard: API 6D, API 598, ISO 14313
Fire Safe Standard: API 607, ISO 10497, API 6FA
Features:
Smaller actuators can be chosen due to their low torque requirements.
Actuator selection is automated for added convenience.
Valve includes fixed lifting lugs for easy handling.
Maintenance is straightforward.
Emergency sealing fittings come as standard.
Seats are renewable for prolonged use.
Choose between metal and soft seats based on your needs.
Features a blow-out-proof stem for added safety.
Optional locking device enhances security.
Instrumentation valves are provided to drain the body cavity.
