ASTM A352 LCC Pressure Seal Gate Valve, 4 IN,2500 LB,API 600

Name: ASTM A352 LCC Pressure Seal Gate Valve, 4 IN,2500 LB,API 600
Brand: www.bossealvalves.com
SKU: 4GPS25JLCC
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 4GPS25JLCC

Key Specifications / Features

Buy high-quality pressure seal bonnet gate valve from a trusted supplier. Our valves are made of ASTM A352 LCC material and come in a size of 4 inches. They have a Class 2500 LB rating and are designed to meet the industry standards of API 600. With DN100 and PN420 specifications, these valves are suitable for demanding applications. Featuring an OS & Y design and flanged ends, they provide reliable sealing. The valves have a 1Cr13+STL.6 trim and are operated by gears. Order now for superior performance and durability.

API 600 Gate Valve 4 Inch Gate Valve DN100 Gate Valve Class 2500 LB Gate Valve PN420 Gate Valve ASTM A352 LCC Gate Valve

Detail Information

4 inch Class 2500 Pressure Seal Gate Valve, API 600, OS & Y, Flanged, ASTM A352 LCC Body, 1Cr13+STL.6 Trim, Gear Operation

Valve Description:
1821021 Gate Valve 4GPS25JLCC
Design Standard: API 600
Structure: Pressure Seal Bonnet
Nominal size: 4 Inch
Nominal class: 2500 LB
Bore Type: Standard Bore
End Connection: Flanged
Operation: Gear
Body Material: ASTM A352 LCC
Trim Material: STL, No.5
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS&Y, Low fugitive emission stem packing available, Renewable Seat

Product Range:
Body material: Carbon Steel,Stainless Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +550℃
Operation: Handwheel, Gear, Motor Actuator
