ASTM A351 CF8M Lug Butterfly Valve, Double Offset, API 609

Name: ASTM A351 CF8M Lug Butterfly Valve, Double Offset, API 609
Brand: www.bossealvalves.com
SKU: 16TB1LWCB
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 16TB1LWCB

Key Specifications / Features

Looking for a top-quality high-performance butterfly valve? Check out our Lug Type of Stainless Steel Double Offset Butterfly Valve with API 609 certification. This valve is 16 inches in size with a 150 LB rating and features a lug design, as well as a durable CF8M body and disc. The valve also includes an RPTFE seat for optimal performance. Trust us for all your industrial valve needs!

Class 150 LB Butterfly Valve Double Offset Butterfly Valves Lug Butterfly Valve RF Butterfly Valve API 609 Cat B Butterfly Valve 16 Inch Butterfly Valve DN400 Butterfly Valve High Performance Butterfly Valve Stainless Steel Butterfly Valve ASTM A351 CF8M Butterfly Valve

Detail Information

Lug Type Stainless Steel High-Performance Butterfly Valve, Double Offset, API 609, 16 Inch, 150 LB, Lug, CF8M body, CF8M Disc, RPTFE seat

Valve Description:
1862005 Double Offset Butterfly Valve 16TB1LWCB
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 16 Inch
Nominal class: 150 LB
End Connection: Lug-RF
Operation: Bare Stem, ISO 5211 Mounting
Body Material: ASTM A351 CF8M
Trim Material: A351 CF8M disc, RPTFE seat
Face to face: API 609
Test and inspection: API 598
Key Features: Long working life for frequent open/close (million cyclings), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics, Standard ISO 5211 Mounting

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
