ASTM A216 WCB Double Offset Butterfly Valve, 14 Inch, 150 LB
Model Number: 14TB1LWCB
Key Specifications / Features
Achieve maximum safety with our API 607 Fire Safe Double Offset Butterfly Valve. This high-performance valve is designed with a 14-inch size, 150 LB pressure rating, LUG connection, and WCB body for optimal durability. The CF8M Disc and RPTFE seat provide reliable and bi-directional sealing. Gear operation makes it easy to use. Trust our fire-safe valve for all your industrial needs.
Detail Information
API 607 Fire Safe Double Offset Butterfly Valve, High Performance, 14 Inch, 150 LB, LUG, WCB body, CF8M Disc, RPTFE seat, Bi-direction sealing, Gear Operation
Valve Description:
1862004 Double Offset Butterfly Valve 14TB1LWCB
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 14 Inch
Nominal class: 150 LB
End Connection: Lug-RF, AS2129 Drilling
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, RPTFE+SS Fire Safe seat
Face to face: API 609
Test and inspection: API 598
Key Features: Fire Safe, Bi-Direction, Long working life for frequent open/close(million cyclings), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics
Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
Valve Description:
1862004 Double Offset Butterfly Valve 14TB1LWCB
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 14 Inch
Nominal class: 150 LB
End Connection: Lug-RF, AS2129 Drilling
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, RPTFE+SS Fire Safe seat
Face to face: API 609
Test and inspection: API 598
Key Features: Fire Safe, Bi-Direction, Long working life for frequent open/close(million cyclings), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics
Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
