ASTM A216 WCB Floating Ball Valve, 2 Inch, 150 LB, API608

Name: ASTM A216 WCB Floating Ball Valve, 2 Inch, 150 LB, API608
Brand: www.bossealvalves.com
SKU: 2BB1RWCB
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 2BB1RWCB

Key Specifications / Features

We Provide Floating Ball Valves, Two Pieces, ASTM A216 WCB, 2 Inch, 150 LB, RF, Lever Lockable, Full Bore, API 608, API 6D, ISO 17292, O-ring for Joint.

Flanged Ball Valve Class 150 LB Ball Valve ASTM A216 WCB Ball Valve Floating Ball Valve API 608 Ball Valve ISO 5211 Ball Valve Mounting Pad Ball Valve 2PCS Ball Valve 2 Inch Ball Valve DN50 Ball Valve Cast Steel Ball Valve PN20 Ball Valve

Detail Information

Product Item: Floating Ball Valve
Model No.: 2BB1RWCB
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 2 Inch
Nominal class: 150 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Lever Lockable
Body Material: ASTM A216 WCB
Trim Material: ASTM A182 F316, RPTFE
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device, ISO 5211 mounting pad

Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
