ASTM A105 Floating Ball Valve, 1-1/2 Inch, 600 LB, RF

Name: ASTM A105 Floating Ball Valve, 1-1/2 Inch, 600 LB, RF
Brand: www.bossealvalves.com
SKU: 1.5BB6RA105
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 1.5BB6RA105

Key Specifications / Features

We Provide China Floating Ball Valves, ASTM A105, 1-1/2 Inch, 600 LB, RF Flanged, API 608, ISO 17292, API 6D, Full Bore, DN40, PN100, Two Pieces, Lever Opt.

Floating Ball Valve Forged Ball Valve API 608 Ball Valve ISO 5211 Ball Valve Mounting Pad Ball Valve DN40 Ball Valve 1.5 Inch Ball Valve PN100 Ball Valve 2PCS Ball Valve ASTM A105 Ball Valve 1 1/2 Inch Ball Valve RF Ball Valve

Detail Information

Product Item: Floating Ball Valve
Model No.: 1.5BB6RA105
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 1-1/2 Inch
Nominal class: 600 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Lever Lockable
Body Material: ASTM A105
Trim Material: ASTM A182 F316, RPTFE
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device, ISO 5211 mounting pad

Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
