ASTM A182 F22 Y Globe Valve, 1 IN, 800 LB, ASME B16.34
Model Number: 1852037
Key Specifications / Features
Our China-based factory specializes in ASME B16.34 globe valves, featuring ASTM A182 F22 material and API 602 compliance. Designed for high performance, our 1-inch (DN25), Class 800 LB valves include a welded bonnet for a secure seal and National Pipe Thread (NPT) ends for easy installation. Operated by a handwheel, these valves are built for durability and efficiency in demanding applications. Trust our expertise for reliable, high-quality valve solutions that meet rigorous industry standards.
Detail Information
ASTM A182 F22 Y Globe Valve, 1 Inch/DN25, 800 LB, Welded Bonnet, NPT End, Handwheel Operation.
Valve Specification:
1852037 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet, Bonnetless
Nominal Size: 1 Inch, DN25
Nominal Class: CL 800 LB
Bore Type: Reduced Bore
Face to Face: MFG'S
Operation: Handwheel
Body Material: ASTM A182 F22, ASTM A182 F11, ASTM A105N, ASTM A182 F316, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Valve Specification:
1852037 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet, Bonnetless
Nominal Size: 1 Inch, DN25
Nominal Class: CL 800 LB
Bore Type: Reduced Bore
Face to Face: MFG'S
Operation: Handwheel
Body Material: ASTM A182 F22, ASTM A182 F11, ASTM A105N, ASTM A182 F316, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
| Product Portfolio | |
| Normal Diameter: | 1/2-2 Inch (DN15-DN50) |
| Pressure Range: | 800-4500 LB |
| Body Material: | Carbon Steel, Stainless Steel, Alloy Steel |
| Operation: | Manual or Actuated |
| End Connection: | BW/SW/NPT |
| Working Temperature: | -29°C to +525°C |
