ASTM A182 F316 Y Type Globe Valve, 1-1/2 IN, 800 LB, API 602
Key Specifications / Features
As a leading API 602 Y Type globe valve fabricator in China, we offer high-quality valves crafted from ASTM A182 F316 material. Our 1-1/2 inch, Class 800 LB globe valves are designed to meet ASME B16.34 standards and feature a bonnetless construction for a streamlined profile. The reduced bore design enhances flow control, while the socket weld ends ensure a secure, leak-proof connection. Engineered for durability and efficiency, our valves are ideal for demanding applications requiring reliable performance. Choose us for robust, precision-engineered valves tailored to your industrial needs.
Request a quote
Detail Information
API 602 Y Type Globe Valve, 1-1/2 Inch, CL 800 LB, ASTM A182 F316 Body, Bonnetless, SW Ends.
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Portfolio:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
| Valve Description: | 1852038 Globe Valve |
| Design Standard: | API 602, ASME B16.34 |
| Structure: | Bonnetless, Welded Bonnet, Bolted Bonnet, Pressure Seal Bonnet |
| Nominal Size: | 1-1/2 Inch |
| Nominal Class: | Class 800 LB |
| Bore Type: | Reduced |
| Face to Face: | MFG'S |
| Operation: | Handwheel |
| Body Material: | ASTM A182 F316, ASTM A182 F11, ASTM A105N, ASTM A182 F22, ASTM A182 F91 |
| Trim Material: | ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316 |
| Test and Inspection: | API 598 |
| End Connection: | BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread) |
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y (Outside Screw & Yoke)
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Portfolio:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
