Alloy Steel Globe Valve, API 6A, 4-1/8 Inch, F51/17-4PH Trim

Name: Alloy Steel Globe Valve, API 6A, 4-1/8 Inch, F51/17-4PH Trim
SKU: GLV-183103028
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading alloy steel globe valve provider in China, we deliver high-quality valves engineered to API 6A specifications for demanding oilfield operations. This 4-1/8 inch globe valve is available with body materials including ASTM A694 F60, F65, AISI 4130, or Inconel, ensuring exceptional durability and resistance to harsh environments. The trim is offered in F51 or 17-4PH for reliable sealing and extended service life. Featuring gear operation, RTJ end connections, and a robust design tested to PSL–PSL3G and PR2 requirements, this valve guarantees safe, efficient, and consistent performance under high-pressure conditions.

Request a quote

Detail Information

Valve Description:
183103028 API 6A Globe Valve
Design Standard: API 6A
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2,000 PSI-15,000 PSI
Bore Type: Standard
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65/Inconel
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: TCC or STL Hardfaced
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A

Key Features:
Material Class: AA, BB, CC, DD, EE, FF, HH
Temperature Class: L, N, P, S, T, U, V, X, Y
Specification: PSL1 - PSL3G
Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2,000 PSI - 15,000 PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +400°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
