ASTM A694 F65 Globe Valve, API 6A, 4-1/4 Inch, 10000 PSI, BW

Name: ASTM A694 F65 Globe Valve, API 6A, 4-1/4 Inch, 10000 PSI, BW
SKU: GLV-183103029
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading ASTM A694 F65 globe valve factory in China, we manufacture reliable valves built to API 6A standards for high-pressure and critical applications. This 4-1/4 inch globe valve is rated for 10,000 PSI, ensuring safe and consistent performance in demanding environments. The body is available in AISI 4130 or Inconel for superior strength and corrosion resistance, while trims are offered in 17-4PH or Inconel for durability. With BW end connections, TCC/STL seating, and smooth gear operation, this valve provides dependable control and long service life under challenging conditions.

Request a quote

Detail Information

Valve Description:
183103029 API 6A Globe Valve
Design Standard: API 6A
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2,000 PSI-15,000 PSI
Bore Type: Standard
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65/Inconel
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: TCC or STL Hardfaced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A

Key Features:
Material Class: AA, BB, CC, DD, EE, FF, HH
Temperature Class: L, N, P, S, T, U, V, X, Y
Specification: PSL1 - PSL3G
Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2,000 PSI - 15,000 PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +400°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
