Bolted Bonnet Globe Valves, API 6A, F65/Inconel, 4-1/16 Inch

Name: Bolted Bonnet Globe Valves, API 6A, F65/Inconel, 4-1/16 Inch
SKU: GLV-183103027
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading bolted bonnet globe valve factory in China, we specialize in manufacturing high-performance valves designed to API 6A standards. This 4-1/16 inch globe valve is rated for 10,000 PSI, making it ideal for critical oilfield and industrial applications. The body is constructed from ASTM A694 F65 or Inconel, ensuring superior strength and corrosion resistance. Equipped with AISI 4140 or F51 trims, RTJ/BW end connections, and reliable gear operation, this valve offers durability, smooth control, and consistent performance under the most demanding service conditions.

Request a quote

Detail Information

Valve Description:
183103027 API 6A Globe Valve
Design Standard: API 6A
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2,000 PSI-15,000 PSI
Bore Type: Standard
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65/Inconel
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: TCC or STL Hardfaced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A

Key Features:
Material Class: AA, BB, CC, DD, EE, FF, HH
Temperature Class: L, N, P, S, T, U, V, X, Y
Specification: PSL1 - PSL3G
Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2,000 PSI - 15,000 PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +400°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
