Metal Seated Butterfly Valve, API 609, ASTM A216 WCC, 2-48 IN

Discover precision in flow control with our Metal Seated Butterfly Valve. Meticulously crafted in China, this valve ranges from 2 to 48 inches, with Class 150-300 LB ratings. Made from ASTM A216 WCC, it adheres to API 609 standards, featuring a Wafer Double Eccentric design suitable for DN50-DN1200 sizes and PN20-PN50 capabilities.

Design Standard: API 609
Body Material: ASTM A216 WCC
Nominal Diameter: NPS 2-48 Inch
Pressure: Class 150-300 LB
End Connection: ASME B16.5, ASME B16.47, BS EN 1092
Test And Inspection: API 598, BS EN 12266
Feature: Metal Seat wafer type, Double eccentric

Product Range

Size: NPS 2 Inch - 48 Inch, DN50-DN1200
Pressure Rating: Class 150-300 LB, PN20-PN50
Material: ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC6, ASTM A217 WC9, ASTM A217 C5, ASTM A217 C12, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A351 CN7M, ASTM A351 CF8C
Design & Manufacturing Standard: API 609, ASME B16.34, BS EN 593
Face to Face: NPS≤24 Inch as per API 609 NPS＞24 Inch as per BS EN 558
Flanged Dimension: ASME B16.5, ASME B16.47, BS EN 1092
Pressure-Temperature: ASME B16.34
Structure Type: Centerline, Double eccentric
Operation Method: Manual, Worm Gear, Electric Actuator, Pneumatic Actuator, Gas Over Oil Actuator

Applicable Standards:

DESIGN & MANUFACTURE CONFORM WITH: API 609, MSS SP-67
CONNECTION DIMENSION CONFORMS WITH: ASME B16.5, ASME B16.47
STRUCTURE & LENGTH CONFORMS WITH: API 609, MSS SP-67, ISO 5752
INSPECTION & TEST CONFORMS WITH: ISO 5208, API 598

Materials of parts
