ASTM A182 F316 Cryogenic Gate Valve, 1 Inch, CL2500

Extension Stem Forged Cryogenic Gate Valve

Name: Forged Steel RTJ Flange Cryogenic Gate Valve
Standard: API 602, BS 5352
Material: Forged Steel F316
Size: 1 Inch, DN25
Pressure: Class 2500 LB, PN420
Connection: Flanged RTJ
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Temperature Of Media: Medium Temperature, Normal Temperature, High Temperature, -65°F - 450°F (-54°C - 232°C)
High Light: Forged Cryogenic Gate Valve, Extension Stems, forge gate valve, Extension Stem High Pressure

Product Range

Size: 1/4 Inch - 4 Inch, DN8-DN100
Pressure: Class 150 LB - 800 LB, 1500 LB, 2500 LB, PN150, PN250, PN420
Connection: Socket Weld, FNPT, BW, RF Flange, RTJ Flange
Temperature: -196°C - 300°C
Design & Manufacture: API 602, ASME B16.34, ISO 15761, ISO 9001, ISO 14001, ISO 18001, CE, TS, DIN, JIS, ISO, GOST
Face-to-face: ASME B16.10
End Dimension
ASME B1.20.1 (NPT)
ASME B16.11 (SW)
ASME B16.25 (BW)
ASME B16.5 (RF, RTJ)
Test & Inspection: API 598
Typical Materials:
Body, Bonnet, Disc: ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L
Stem: ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L
