High Pressure Sealed Gate Valve, API 602, 1 Inch, 2500 LB

Name: High Pressure Sealed Gate Valve, API 602, 1 Inch, 2500 LB
SKU: VF-231212-FSGV-07
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a premier High-Pressure Sealed Gate Valve Maker, we specialize in crafting reliable and durable valves. Our 1-inch gate valve is designed for Class 2500 LB applications, ensuring robust performance in demanding conditions. Constructed from high-quality ASTM A105N material, our valves are built to withstand high pressures. Featuring NO.5 Trim, these valves are equipped with precision components for optimal flow control.

Request a quote

Detail Information

Standard: API 602
Material: ASTM A105N
Trim: NO.5
Size: 1 Inch
Class Rate: 2500 LB
Ends: NPT, NPT * SW, SW
Operating: Hand Wheel
Wall Thickness: API 602, ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1.
Butt Welding Ends: ASME B16.25.
Pressure Testing: API 598.

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
