Bellow Seal Gate Valve, API 602, ASTM A105N, 3/4 IN, 800 LB

Name: Bellow Seal Gate Valve, API 602, ASTM A105N, 3/4 IN, 800 LB
SKU: VF-231212-FSGV-12
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Are you in search of a dependable Bellow Seal Gate Valve? Look no further! Our valves, crafted in accordance with API 602 standards, offer a robust solution for fluid control. Made from high-quality ASTM A105N forged steel, these valves come in a 3/4-inch size, Class 800 LB rating, and NO.5 Trim for precise flow regulation. With user-friendly hand wheel operation and compatibility with NPT, NPT * SW, and SW Ends, our Bellow Seal Gate Valves are the ideal choice for your industrial needs.

Request a quote

Detail Information

Standard: API 602
Material: ASTM A105N
Trim: NO.5
Size: 3/4 Inch
Class Rate: 800 LB
Ends: NPT, NPT*SW, SW
Operating: Hand Wheel
Wall Thickness: API 602, ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1.
Butt Welding Ends: ASME B16.25.
Pressure Testing: API 598.

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
