ASTM A105 Globe Valve, ASME B16.34, 1/4-2 Inch, 150-800 LB

Name: ASTM A105 Globe Valve, ASME B16.34, 1/4-2 Inch, 150-800 LB
SKU: VF-231213-GLV-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a reputable ASTM A105 Globe Valve factory, we specialize in manufacturing valves that meet the highest standards. Our valves, ranging from 1/4 to 2 inches, are designed for Class 150-800 LB applications, adhering to ASME B16.34 and BS 5352 specifications. Featuring a Bolted Bonnet for secure sealing, our Globe Valves come in both Full and Standard Port configurations, ensuring versatile fluid control.

Request a quote

Detail Information

Design Construction:
ASME B16.34, BS 5352
Size: 1/4 Inch, 3/8 Inch, 1/2 Inch, 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch, 2 Inch, DN6, DN10, DN15, DN20, DN25, DN32, DN40, DN50
Class: 150 LB, 300 LB, 400 LB, 600 LB, 800 LB, PN20, PN50, PN63, PN100, PN130
Testing according to api 598
Socket Weld Ends to ASME B16.11
Screwed Ends (NPT) to ASME B1.20.1
Butt Welding Ends to ASME B16.25
Spiral-wound gasket
Integal backseat
Loose solid disc
Marking MSS SP25
Outsind Screw and Yoke(OS&Y)
Self aligning two piece packing gland

Ratings:
- carbon steel class 800 1975 psig @ 100°F 138 bar + 38°C
- carbon steel class 1500 3705 psig @ 100°F 255 bar + 38°C

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.
