API 602 Gate Valve, ASTM A182 F22, 1 IN, 2500 LB, Reduce Port
Model Number: VF-240220-FSGV-04
Key Specifications / Features
Manufacturer of Reduce Port Gate Valves: These valves are meticulously crafted with Forged Steel ASTM A182 F22 material, ensuring durability and reliability. With a compact size of 1 inch (DN25) and a robust design meeting API 602 standards, they are suitable for high-pressure applications. Rated for Class 2500 LB (PN420), these valves feature butt weld ends and are tested according to API 598 standards for quality assurance.
Detail Information
Standard: API 602
Material: ASTM A182 F22
Size: 1 Inch, DN25
Pressure: Class 2500 LB, PN420
End Connection: BW
Port: Reduce Port
Operating: Hand Wheel
Test & Inspection: API 598
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29ºC - +540ºC
Material: ASTM A182 F22
Size: 1 Inch, DN25
Pressure: Class 2500 LB, PN420
End Connection: BW
Port: Reduce Port
Operating: Hand Wheel
Test & Inspection: API 598
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29ºC - +540ºC
