API 600 Flanged Gate Valve, WCB, 24 Inch, Class 600, RF

API 600 Flanged Gate Valve Maker: ASTM A216 WCB Gate Valve with RF Flange, 24 Inch, 600 LB, OS & Y, Rising stem, Flexible Wedge, API 600, API 6D, BS 1414.

Design standard: API 600.
Body material: ASTM A216 WCB.
Nominal diameter: 24 Inch.
Pressure: Class 600 LB.
End connection: RF Flange.
Face to face: ASME B16.10.
Working temperature: -29℃ - +300℃.
Test and inspection: API 598.

Size: 2 - 48 Inch.
Pressure: CLASS 150-1500 LB.
OS & Y, Rising stem, Flexible Wedge.
Bolted Bonnet,Threaded or welded seat ring.
Material: ASTM A216 WCB, ASTM A217 WC6, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A351 CN7M.

Standards compliance
Design and Manufacture: ANSI B16.34, API 600, API 6D, API 603, BS 1414.
Face to face(end to end): ANSI B16.10, API 6D.
Flanged connection: 2-24 Inch to ANSI B16.5, 22 Inch, 26-36 Inch to MSS SP-44 to API 605 on Request.
Test and inspection: API 598, API 6D.
Butt welded end: ANSI B16.5.

1. Anti-friction ball thrust bearing: Reduces friction between mating parts to ensure smooth operation.
2. Grub screw: Secures yoke nut in the bonnet.
3. Grease nipple: Supplies lubricant to the mating parts.
