3 Way Ball Valve, T Port, L Port, 1/2-8 Inch, 150-300 LB
Key Specifications / Features
3 Way Ball Valve Maker: 3 Ways Ball Valve, T Port, L Port, SS 304, 304L, PTFE, PPL Seat Seal, 1/2-8 Inch, 150-300 LB, Flange, Reduce Port, API 6D.
Request a quote
Detail Information
3 Way Ball Valve, 4 Way Ball Valve, T Port Thread 3 Way Ball Valve, L Port Thread 3 Way Ball Valve, Flange 3 Way T Port Ball Valve, Flange 3 Way L Port Ball Valve, Three Way Stainless Steel T/L Port Ball Valve.
The three way and four way ball valve have an L-shaped or T-shaped hole through the middle. It is easy to see that a T-port valve can connect any pair of ports, or all three, but in the 45 degree position all three ports might be disconnected. The L valve can connect the center port to either side port, or disconnect all three, but it cannot connect the side ports together.
Flange 3 Way Ball Valve is a true multi-way ball valve with balanced 4-seat construction. This full port valve is available in a variety of flow plans. This valve can replace multiple 2-way valves in a process system. A standard ISO 5211 pattern mounting pad allows for easy assembly of pneumatic and electric actuators.
Product Features:
L type and T type port for choice.
Blow-out proof stem design.
PTFE/RPTFE/PPL seat seal. (Seat seal material could be decided by customer's request or according to valve's media & temp.)
ISO 5211 high mounting pad for option.
Fire-proof and anti-static design.
Operation: Hand wheel, Lockable handle, Pneumatic actuator and Electric Actuator.
The three way and four way ball valve have an L-shaped or T-shaped hole through the middle. It is easy to see that a T-port valve can connect any pair of ports, or all three, but in the 45 degree position all three ports might be disconnected. The L valve can connect the center port to either side port, or disconnect all three, but it cannot connect the side ports together.
Flange 3 Way Ball Valve is a true multi-way ball valve with balanced 4-seat construction. This full port valve is available in a variety of flow plans. This valve can replace multiple 2-way valves in a process system. A standard ISO 5211 pattern mounting pad allows for easy assembly of pneumatic and electric actuators.
Product Features:
L type and T type port for choice.
Blow-out proof stem design.
PTFE/RPTFE/PPL seat seal. (Seat seal material could be decided by customer's request or according to valve's media & temp.)
ISO 5211 high mounting pad for option.
Fire-proof and anti-static design.
Operation: Hand wheel, Lockable handle, Pneumatic actuator and Electric Actuator.
| 1. Material | SS304, ASTM A182 F316, ASTM A182 304L, ASTM A182 316L, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A216 WCB, etc. |
| 2. Size | 1/2 Inch-8 Inch (DN15-DN200). |
| 3. Connection ends | Flange, Thread. |
| 4. Port | Reduce Port. |
| 5. Working Pressure | Class 150-300 LB. |
| 8. Working Temp. | -20-300ºC, or according to customer requirements of different industry. |
| 9. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid. |
| 10.Design & manufacture standard | API 6D |
| 11. Pressure & Temp. standard | ASME 16.34. |
| 12. Face to face dimension standard | ASME 16.10. |
| 13. Flange standard | ASME16.5, ASME 16.34. |
| 14. Inspection & Testing | API 598, API 6D. |
