H42X Silent Check Valve, Cast iron, WCB
Model Number: SJ-CV-12
Key Specifications / Features
China Silent Check Valve Manufacturer Shinjo Supplies H42X Silent Check Valve, Cast iron, WCB.
Detail Information
H42X Silent Check Valves is mounted on the outlet pipe of the pump for the security pipes for avoiding the reversal rotation caused by the pressed water stream to impact the pump's stopping. This valve is small volume, light and convenient. With guiding device, flexible closing, linear sealing, excellent check result and can reducing the closing noise efficiently.
Specifications
| PN (MPa) | 1.0 | 1.6 | 2.5 | |
| Test pressure (MPa) | Shell Strength | 1.5 | 2.4 | 3.75 |
| Sealing Performance | 1.1 | 1.76 | 2.75 | |
| Temperature | ≤ 80°C | |||
| Fluid | Water, Oil | |||
Materials
| Name | Body, Seat | Plug | Sealing | Spring | |
| Material | CI, Steel casting, Cast-iron, Stainless steel | Cast Copper, Stainless Steel | NBR | Stainless steel | |
Dimensions
| DN mm | PN 1.0 | PN 1.6 | PN 2.5 | ||||||||||||||||||
| L | b | f | D2 | D | D1 | Z-Φd | L | b | f | D2 | D | D1 | Z-Φd | L | b | f | D2 | D | D1 | Z-Φd | |
| 40 | 115 | 18 | 2 | 85 | 150 | 110 | 4-18 | 115 | 18 | 2 | 85 | 150 | 110 | 4-18 | 115 | 18 | 2 | 85 | 150 | 110 | 4-18 |
| 50 | 120 | 20 | 3 | 102 | 165 | 125 | 4-18 | 120 | 20 | 3 | 102 | 165 | 125 | 4-18 | 120 | 20 | 3 | 99 | 165 | 125 | 4-18 |
| 65 | 130 | 20 | 3 | 122 | 185 | 145 | 4-18 | 140 | 20 | 3 | 122 | 185 | 145 | 4-18 | 140 | 22 | 3 | 118 | 185 | 145 | 8-18 |
| 80 | 150 | 22 | 3 | 133 | 200 | 160 | 8-18 | 150 | 22 | 3 | 133 | 200 | 160 | 8-18 | 150 | 24 | 3 | 132 | 200 | 160 | 8-18 |
| 100 | 165 | 24 | 3 | 158 | 220 | 180 | 8-18 | 180 | 24 | 3 | 158 | 220 | 180 | 8-18 | 180 | 24 | 3 | 156 | 235 | 190 | 8-22 |
| 125 | 190 | 26 | 3 | 184 | 250 | 210 | 8-18 | 210 | 26 | 3 | 184 | 250 | 210 | 8-18 | 210 | 26 | 3 | 184 | 270 | 220 | 8-26 |
| 150 | 210 | 26 | 3 | 212 | 285 | 240 | 8-22 | 220 | 26 | 3 | 212 | 285 | 240 | 8-22 | 220 | 28 | 3 | 211 | 300 | 250 | 8-26 |
| 200 | 255 | 28 | 3 | 268 | 340 | 295 | 8-22 | 255 | 30 | 3 | 268 | 340 | 295 | 12-22 | 255 | 30 | 3 | 274 | 360 | 310 | 12-26 |
| 250 | 310 | 28 | 3 | 320 | 395 | 350 | 12-22 | 310 | 32 | 3 | 320 | 405 | 355 | 12-26 | 310 | 32 | 3 | 330 | 425 | 370 | 12-30 |
| 300 | 362 | 28 | 4 | 370 | 445 | 400 | 12-22 | 362 | 32 | 4 | 370 | 460 | 410 | 12-26 | 362 | 34 | 4 | 389 | 485 | 430 | 16-30 |
| 350 | 380 | 30 | 4 | 428 | 500 | 460 | 16-22 | 430 | 36 | 4 | 428 | 520 | 470 | 16-26 | 430 | 38 | 4 | 450 | 555 | 490 | 16-33 |
| 400 | 450 | 32 | 4 | 482 | 565 | 515 | 16-26 | 490 | 38 | 4 | 482 | 580 | 525 | 16-30 | 490 | 40 | 4 | 505 | 620 | 550 | 16-36 |
| 450 | 545 | 32 | 4 | 532 | 615 | 565 | 20-26 | 545 | 40 | 4 | 532 | 640 | 585 | 20-30 | 545 | 42 | 4 | 555 | 670 | 600 | 20-36 |
| 500 | 580 | 34 | 4 | 585 | 670 | 620 | 20-26 | 580 | 42 | 4 | 585 | 715 | 650 | 20-33 | 580 | 44 | 4 | 615 | 730 | 660 | 20-36 |
