Unidirectional Salgging Knife Gate Valve, 150 LB, 28 Inch

Name: Unidirectional Salgging Knife Gate Valve, 150 LB, 28 Inch
SKU: MFRS-230905-GV-10
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Experience superior quality with our Unidirectional Slagging Knife Gate Valve Plant. Crafted from ASTM A351 CF3M, CF8M, CF8, and ASTM A216 WCB materials, these valves are designed for reliability. With a 28-inch size (DN700) and suitability for 3 Bar and 150 LB applications, they feature SS 316L and SS 304 Discs for top-notch performance.

Request a quote

Detail Information

Design Standard: MSS SP-81
Flange Standard: PN10, PN16, 150LB , JIS 10K, TABLE E/D
Face to Face: MSS SP-81
Testing Standard: EN 12266
Size: 28 Inch, DN700
Pressure: 3 Bar, 150 LB
Transmission: Manual, Electric, Pneumatic, Hydraulic, Sprocket, Electro-Hydraulic, Gear
Main material: ASTM A351 CF3M, CF8M, CF8, ASTM A216 WCB, Ductile Iron GGG40
Disc material: SS 316L, SS 304
Sealing material: EPDM, Metal to Metal
Packing: PTFE, High WaterBased, Rubber Packing, Graphite
Applicable medium: Applicable for Dust, Solid Particles, Coal, Oil, Chemical and so on. Slag, cinder, Dislagging Recommend
