Parallel Slide Gate Valve, ASTM A216 WCB, 28 IN, 600 LB, RF

Name: Parallel Slide Gate Valve, ASTM A216 WCB, 28 IN, 600 LB, RF
SKU: MFRS-230818-GV-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Presenting our collection of Parallel Slide Gate Valves, engineered to perfection. Crafted from durable Forged Carbon Steel ASTM A216 WCB material, these valves adhere to the API 6D and DIN 3352 GS C25 standards. With a size of 28 inches (DN700), they operate efficiently under both PN100 and 600 LB pressure ratings. Featuring RF Flange connections, these valves are designed for optimal performance in various applications.

Request a quote

Detail Information

Detail Infomation

Name: Flat Gate Valve
Standard: API 6D, DIN 3352 GS C25
Material: ASTM A216 WCB Forged Carbon Steel
Pressure: PN100, Class 600 LB
Size: 28 Inch, DN700
Connection: RF Flange
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Temperature Of Media: -65℉-450℉ (-54℃-232℃)

Product Range

Product Material: Carbon & Low-alloy steel, STL, Nickel bare alloy, Stainless Steel, Alloy Steel
Design Standard: API 6D, ASME B16.34
Size: 2 - 40 Inch, DN50-DN1000
Pressure: Class 150-900 LB
Test: API 6D
End: RF, Socket Welded
Operation: Handwheel, Gear, Electric, Pneumatic, Hydraulic

Design Features:

Full Bore design
Double block & bleed
Self cavity relief
Single-disc or double disc
Emergency Sealant injection
Diversion hole type or non-diversion hole
Flanged or buttwelding ends
Fire safe design to API 6FA/ API 607
