Metal Seated Ball Valve, ASTM A105N, 24 Inch, Class 300 LB

Name: Metal Seated Ball Valve, ASTM A105N, 24 Inch, Class 300 LB
SKU: MFRS-231205-TMBV-08
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore excellence in fluid control with our API 6D metal-seated ball valve from our manufacturing facility in China. This valve, constructed from robust carbon steel ASTM A105N, boasts a 24-inch size and is rated at Class 300 LB, making it ideal for demanding applications. With a DN600 size and PN50 rating, it delivers reliable performance in various industrial settings.

Request a quote

Detail Information

Valve description：
Design: API 6D.
Body: ASTM A105N.
Nominal size: 24 Inch.
Nominal class: 300 LB.
End Connection: RF flange.
Face to face: as per ASME B16.10.
Test and inspection: API 598.

Product Range：
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 60 Inch (DN15 - DN1500).
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN420).
Working temperature: -46℃ - +540℃.
