Gearbox Operated Ball Valve, API 6D, A216 WCB, 24 IN, 300 LB
Model Number: MFRS-240109-TMBV-05
Key Specifications / Features
As a leading API 6D ball valve manufacturer, we take pride in delivering excellence in fluid control solutions. Our 24-inch ball valve, constructed from robust ASTM A216 WCB material, adheres to Class 300 LB standards, ensuring reliable performance in diverse applications. With a DN600 size and PN50 pressure rating, this valve is designed for optimal flow control.
Detail Information
Design Standard: API 6D.
Body Material: ASTM A216 WCB.
Nominal Diameter: 24 Inch, DN600.
Pressure: Class 300 LB, PN50.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃ - +200℃.
Mode of Operation: Gearbox.
Test and Inspection: API 6D, API598.
Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2 - 60 Inch (DN50 - DN1500).
End Connection: BW, Flanged.
Pressure Range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃ - +200℃.
Body Material: ASTM A216 WCB.
Nominal Diameter: 24 Inch, DN600.
Pressure: Class 300 LB, PN50.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃ - +200℃.
Mode of Operation: Gearbox.
Test and Inspection: API 6D, API598.
Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2 - 60 Inch (DN50 - DN1500).
End Connection: BW, Flanged.
Pressure Range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃ - +200℃.
