Forged Steel Angle Type Globe Valve, PN160-PN420

Forged Steel Angle Type Globe Valve, PN160-PN420

Key Specifications / Features

Forged Steel Angle Type Globe Valve Company in China: Forged Steel Angle Globe Valve for High-Pressure Steam, PN160-PN420, RF, Manual Operation.
RF Angle Type Globe Valve PN420 Angle Type Globe Valve PN160 Angle Type Globe Valve High-Pressure Steam Angle Type Globe Valve Forged Steel Angle Type Globe Valve Manual Angle Type Globe Valve
Share:

Detail Information

Product Name: Forged Steel Angle Type Globe Valve.
Body: Cast steel, Ductile iron or Malleable cast steel.
Stem: Carbon Steel.
Connection: Flange connection.
Operation: Manual.
Nominal pressure: PN160-PN420.
Seat sealing surface: STL hard alloy.
Application: for high-pressure steam.

The Forged Steel Angle Type Globe Valve manufactured by Topper Valve with carbon steel stem, flange connection, manual operation, nominal pressure PN160-PN420, seat sealing surface STL hard alloy, used for high-pressure steam.

Product parts and materials
product type Part Name
Valve body   Stem   Filler Sealing surface Gasket Fastener
  A   Cast steel Carbon steel PTFE Babbitt   Asbestos rubber sheet     High quality carbon steel
  B   Ductile iron Carbon steel   PTFE   Babbitt Asbestos rubber sheet High quality carbon steel
  C     Malleable cast steel     Carbon steel   PTFE Babbitt Asbestos rubber sheet High quality carbon steel

Product appearance and structure size
Nominal diameter   Main external dimensions and connection dimensions
L D D1 D2 b Z-d H D0
A
15 130 95 65 45 14-2 4-Φ14 170 120
20 150 105 75 55 14-2 4-Φ14 190 140
25 160 115 85 65 14-2 4-Φ14 205 160
32 180 135 100 78 16-2 4-Φ18 270 180
40 200 145 110 85 16-3 4-Φ18 310 200
50 230 160 125 100 16-3 4-Φ18 358 240
65 290 180 145 120 18-3 4-Φ18 373 240
80 310 195 160 135 20-3 8-Φ18 435 280
100 350 215 180 155 20-3 8-Φ18 500 300
125 400 245 210 185 22-3 8-Φ18 614 320
150 480 280 240 210 24-3 8-Φ23 674 360
200 600 335 295 265 26-3 12-Φ23 811 400
250 650 405 355 320 30-3 12-Φ25 969 450
300 750 460 410 375 30-3 12-Φ25 1145 580
350 850 520 470 435 34-4 16-Φ25 1280 640
400 980 580 525 485 36-4 16-Φ30 1452 640
B
15 130 95 65 45 16-2 4-Φ14 170 120
20 150 105 75 55 16-2 4-Φ14 190 140
25 160 115 85 65 16-2 4-Φ14 205 160
32 180 135 100 78 18-2 4-Φ18 270 180
40 200 145 110 85 18-3 4-Φ18 310 200
50 230 160 125 100 20-3 4-Φ18 358 240
65 290 180 145 120 22-3 8-Φ18 373 240
80 310 195 160 135 22-3 8-Φ18 435 280
100 350 230 190 160 24-3 8-Φ23 500 300
125 400 270 220 188 28-3 8-Φ25 614 320
150 480 300 250 218 30-3 8-Φ25 674 360
200 600 360 310 278 34-3 12-Φ25 811 400
250 650 425 370 332 36-3 12-Φ30 969 450
300 750 485 430 390 40-4 16-Φ30 1145 580
350 850 550 490 448 44-4 16-Φ34 1280 640
400 980 610 550 505 48-4 16-Φ34 1452 640
