ASME B16.34 Y Type Globe Valve, BW End, PN1.6 to 6.4 Mpa
Key Specifications / Features
ASME B16.34 Y Type Globe Valve Factory in China: High Pressure Y Globe Valve, ASME B16.34, 1Cr13, 25Cr2Mo1V, 17-4PH Stem, BW End, 1.6 to 6.4 Mpa.
Detail Information
Product Name: ASME B16.34 High Pressure Y Type Globe Valve.
Design and manufacture of standards: ASME B16.34.
Valve stem: 1Cr13, 25Cr2Mo1V or 17-4PH.
Butt welding end: ASME B16.25.
Nominal pressure: 1.6 to 6.4 Mpa.
The ASME B16.34 High Pressure Y Type Globe Valve manufactured by Topper Valve is designed by ASME B16.34 with nominal pressure PN1.6 to 6.4Mpa and working temperature -29 to 550℃, which can be operated manually or pneumatically.
Product parts materials
Product appearance and structure size
Design and manufacture of standards: ASME B16.34.
Valve stem: 1Cr13, 25Cr2Mo1V or 17-4PH.
Butt welding end: ASME B16.25.
Nominal pressure: 1.6 to 6.4 Mpa.
The ASME B16.34 High Pressure Y Type Globe Valve manufactured by Topper Valve is designed by ASME B16.34 with nominal pressure PN1.6 to 6.4Mpa and working temperature -29 to 550℃, which can be operated manually or pneumatically.
Product parts materials
| Part Name | Material |
| Body | 25+Stellite 21,F22+Stellite 21 |
| Disc | 25+Stellite 6,F22+Stellite 6 |
| Valve stem | 1Cr13,25Cr2Mo1V,17-4PH |
| Stuffing box | 25,F22 |
| cap | 25,F22 |
| Stem nut | QAL9-4,D2 |
| Platen | 1Cr13,F22 |
| filler | Import GARLOCK folder stainless steel wire braided flexible graphite |
| Pad filler | 1Cr13 |
| Gasket | Clip 316 high-soft graphite |
Product appearance and structure size
| Caliber | Class 1500 | Class 2500 | ||||||||
| L | D | W | H | Wt(kg) | L | D | W | H | Wt (kg) |
|
| 1/2IN | 152 | 60 | 216 | 298 | 13 | 152 | 60 | 216 | 298 | 13 |
| 3/4IN | 152 | 60 | 216 | 298 | 13 | 152 | 60 | 216 | 298 | 13 |
| 1IN | 152 | 60 | 216 | 298 | 13 | 152 | 60 | 216 | 298 | 13 |
| 1-1/4IN | 170 | 81 | 216 | 326 | 15.8 | 170 | 81 | 216 | 326 | 15.8 |
| 1-1/2IN | 170 | 81 | 216 | 326 | 15.8 | 170 | 81 | 216 | 326 | 15.8 |
| 2IN | 272 | 102 | 363 | 427 | 37.8 | 272 | 102 | 363 | 427 | 37.8 |
| 2-1/2IN | 325 | 122 | 406 | 474 | 63 | 325 | 122 | 406 | 474 | 63 |
| 3IN | 325 | 122 | 406 | 474 | 63 | 325 | 122 | 406 | 474 | 63 |
| 4IN | 325 | 122 | 406 | 474 | 63 | 325 | 122 | 406 | 474 | 63 |
