Cryogenic Ball Valve
Key Specifications / Features
Cryogenic Ball Valve Manufacturer in China: Cryogenic Ball Valve, ASTM A352 LCB, 1/2 Inch - 12 Inch, CL150 - CL2500, API 6D, API 608, ASME B16.34, Pneumatic.
Request a quote
Detail Information
Topper provides cryogenic ball valves that have the following features:
1. A cryogenic ball valve is a kind of valve that is mainly for ethylene, liquefied natural gas and other chemical devices. Cryogenic ball valves are mainly divided into cryogenic floating ball valves and cryogenic standing ball valves.
2. Long-necked structure is not usually applied for temperature above -50℃, and applied for temperature below -50℃. It aims to protect the stuffing box, locate stuffing box far away from low temperature, and guarantee sealing effect of the stuffin. Cold insulation materials can also be used to prevent loss of cold energy.
Product Details
Design standard: API 6D, API 608, ASME B16.34.
Length of structure: API 6D, ASME B16.10.
Flange connecting end: ASME B16.5.
Butt welding connecting end: ASME B16.25.
Wall thickness: ASME B16.34.
Inspection and test: API 6D, API 598.
Pressure and temperature rating: ASME B16.34.
Fireproof test: API 607, API 6FA.
Product scope: NPS 1/2 Inch - NPS 12 Inch, CL150 - CL2500.
Main body material: ASTM A352 LCB, ASTM A352 LCC, ASTM A352 LC3, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A350 LF2, ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, etc.
Drive device: handle, worm wheel, electric, pneumatic, pneumatic- hydraulic, electro-hydraulic, etc.
1. A cryogenic ball valve is a kind of valve that is mainly for ethylene, liquefied natural gas and other chemical devices. Cryogenic ball valves are mainly divided into cryogenic floating ball valves and cryogenic standing ball valves.
2. Long-necked structure is not usually applied for temperature above -50℃, and applied for temperature below -50℃. It aims to protect the stuffing box, locate stuffing box far away from low temperature, and guarantee sealing effect of the stuffin. Cold insulation materials can also be used to prevent loss of cold energy.
Product Details
Design standard: API 6D, API 608, ASME B16.34.
Length of structure: API 6D, ASME B16.10.
Flange connecting end: ASME B16.5.
Butt welding connecting end: ASME B16.25.
Wall thickness: ASME B16.34.
Inspection and test: API 6D, API 598.
Pressure and temperature rating: ASME B16.34.
Fireproof test: API 607, API 6FA.
Product scope: NPS 1/2 Inch - NPS 12 Inch, CL150 - CL2500.
Main body material: ASTM A352 LCB, ASTM A352 LCC, ASTM A352 LC3, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A350 LF2, ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, etc.
Drive device: handle, worm wheel, electric, pneumatic, pneumatic- hydraulic, electro-hydraulic, etc.
