ASTM A216 WCB Swing Check Valve, API 6D, 24 Inch, 150 LB, RF

Name: ASTM A216 WCB Swing Check Valve, API 6D, 24 Inch, 150 LB, RF
SKU: MFRS-230814-CV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

In search of a trustworthy supplier for full-open swing check valves? Your search ends here! Our valves are meticulously crafted from premium materials and are accessible in a range of dimensions and pressure classifications. This includes 24-inch valves boasting a class 150 LB designation, DN600, and PN20 specifications. Aligned with API 6D standards, our valves feature an expansive bore design, seat that can be renewed, bonnet secured with bolts, and an RF end. Manufactured using ASTM A216 WCB material, these valves assure consistent and enduring functionality. Connect with us today to explore our selection of full open swing check valves and discover how we can cater to your requirements!

Request a quote

Detail Information

Structure: Bolted Bonnet, Full Open
Design Standard: API 6D
Trim Material: Monel
Body Material: ASTM A216 WCB
Face to face: ASME B16.10
Test and inspection: API 598
Nominal size: 24 Inch
Nominal class: 150 LB
Bore Type: Full Bore
End Connection: RF (Raised Face)
Key Features: Swing Disc, Renewable Seat, Full Open

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
Working temperature: -29℃ - +425℃
End connection: RF, RTJ, BW
