Stainless Steel Floating Ball Valve, A351 CF8, 3 Inch, CL150

The Stainless Steel Ball Valve Supplier offers a high-quality 80 mm floating ball valve, designed with ASTM A351 CF8 stainless steel for superior durability and corrosion resistance. This 3-inch (DN80) valve is rated for Class 150 LB and PN20 pressure classes, featuring lever operation for easy control. It comes with raised face (RF) flanged ends, ensuring secure and reliable connections in various industrial applications.

Product Name: Stainless Steel Floating Ball Valve
Type: Floating Ball Valve
Body Material: ASTM A351 CF8
Size: 3 Inch, DN80, 80 mm
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Lever
Temperature Range: -46°C to 120°C

The cast floating ball valve design supports the ball with two PTFE seats，one on the upstream side and one on the downstream side. When upstream pressure acts on the ball, it pushes the ball against the downstream seat, creating a tight and reliable shutoff for fluid control. All cast floating ball valves manufactured by KOSEN feature high-quality, reliable castings and fire-safe designs certified to BS 6755, API 607, and API 6FA. They meet all applicable ASME standards. Floating ball valves are available in one-piece unibody, two-piece split-body, and three-piece bolted-body configurations. They are designed and manufactured in accordance with the latest international standards, including API 6D, ASME B16.34, BS 5351, or equivalent specifications. Standard features include fire-safe construction, anti-static design, and a blowout-proof stem.

Technical Specification

» Product: Cast Floating Ball Valve
» Size Ranges: NPS 1/2-10 Inch (DN15-DN250)
» Design Pressure: Class 150-600 LB (PN10-PN100)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Specials
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other specials
» Seat Materials: NYLON, RPTFE, PEEK
» Ends Connections: FF and RF flange, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A

Structural Diagram

Product Features

» Low operating torque
» Emergency sealing device
» Fireproof structure design
» Anti-static structure
» Reliable seat-sealing structure
» Special structure for automatic upstream pressure relief
» Blowout-proof stem with stem flyout prevention design
» Corrosion resistance and sulfide stress resistance
» Optional locking device or stem extension
» Optional direct mounting to ISO 5211
» Full port or reduced bore
