Rising Stem Globe Valve, ASME B16.34, A216 WCB, 8 IN, 150 LB

Name: Rising Stem Globe Valve, ASME B16.34, A216 WCB, 8 IN, 150 LB
SKU: KV-20250108-CSGLV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Rising Stem Globe Valve, manufactured in China, is designed to ASME B16.34 standards with a carbon steel ASTM A216 WCB body. Featuring an 8-inch (DN200) size, Class 150 LB (PN20) pressure rating, and RF flanged ends, this valve provides reliable flow regulation. It includes an OS&Y (Outside Stem and Yoke) design, a bolted bonnet for secure sealing.

Request a quote

Detail Information

Product Name: Rising Stem Globe Valve
Features: OS&Y, Bolted Bonnet, Rising-stem
Design Standard: ASME B16.34
Body Material: ASTM A216 WCB
Size: 8 Inch, DN200
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Manual

Cast Steel Globe Valves are engineered to achieve a leakage of less than 100 ppm (parts per million) of volatile organic compounds (VOCs). Extensive baseline laboratory testing, including both static and cycle tests, has been conducted to establish critical design parameters for low-emission sealing, specifically in the KOSEN stem packing and bonnet gasket sealing areas. An in-house testing procedure has been developed and is regularly performed to ensure that the product design and manufacturing standards consistently result in Cast Steel Globe Valves meeting the maximum VOC leakage of 100 ppm before shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2–24 Inch (DN15–DN600)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, and other fluids
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) to international standards
» Operation: Handwheel, bevel gear, electric, pneumatic
» Applications: Electric power, petroleum refining, petrochemical engineering, offshore oil, urban water engineering, chemical engineering
» Design and Manufacture: ASME B16.34, BS 1873, DIN 3356
» Face to Face (End to End): ANSI B16.10, EN 558 series
» Flanged Connection: ANSI B16.5, EN 1092 series
» Butt Welded End: ANSI B16.25
» Test and Inspection: API 598, ISO 5208, EN 12266-1

Product Features

» OS&Y (Outside Stem and Yoke), bolted bonnet, rising stem
» Short stroke for easy, quick open/close
» For large size and high pressure: relief cone = internal bypass
» Disc sealing: flat sealing, throttle cone = regulating disc
» Body seat: threaded seat or welded seat
» Metal-sealed (API Trim #1, #5, #8, #10, etc.)
» Optional locking device or stem extension
» Optional direct mounting to ISO 5211
» Reduce port
