Panel Mounted Needle Valve, SS 304, 3/4 Inch, DN20, PN700

Name: Panel Mounted Needle Valve, SS 304, 3/4 Inch, DN20, PN700
SKU: KV-20250306-NV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Panel Mounted Needle Valve is crafted from durable stainless steel SS 304, offering excellent corrosion resistance. With a 3/4-inch size (DN20) and a pressure rating of PN700, it is designed for high-pressure applications. The valve features female/internal threaded ends with an M20 * 1.5 thread size, providing a secure and precise connection.

Request a quote

Detail Information

Product Name: Panel Mounted Needle Valve
Body Material: Stainless Steel SS 304
Size: 3/4 Inch, DN20
Pressure: PN700
End Connection: Female/Internal Thread
Operation: Manual
Threads Size: M20 x 1.5

Product Range

Model: J01P-H15Y
Nominal Diameter: DN6-DN80, 1/8-3 Inch
Pressure: 40 MPa – 100 MPa
Material: Stainless Steel, Carbon Steel
Applicable Temperature: -29°C to +570°C

The stainless steel panel-type ultra-high pressure needle valve is a precision valve designed for fine flow regulation. Featuring a needle-shaped valve disc, it allows for gradual and precise adjustment of flow from fully closed to fully open. The needle valve plug, typically made from quenched steel, ensures smooth and consistent flow control. The valve seat is constructed from soft materials like tin or copper, providing a reliable seal. The sealing between the valve needle and seat is achieved via a tight-fitting conical surface. The needle valve comes with two taper options: 1:50 and 60-degree cone angles, both of which require fine grinding. Additionally, the sealing between the valve stem and valve seat is ensured by corrugated pipes, contributing to the valve's durability and performance in high-pressure applications.
