Electric Control Valve, ASTM A216 WCB, 4 Inch, 150 LB, RF

Name: Electric Control Valve, ASTM A216 WCB, 4 Inch, 150 LB, RF
SKU: KV-20250102-CV-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Electric Control Valve, manufactured in China, is a non-balanced, single seat type with a carbon steel ASTM A216 WCB body. It features a 4-inch (DN100) size, Class 150 LB, and PN16 pressure rating. Equipped with RF ends, this valve offers precise flow control in industrial applications and is ideal for integration with electric actuators.

Request a quote

Detail Information

Product Name: Electric Actuator Control Valve
Features: Non-balanced, Single Seat
Body Material: ASTM A216 WCB
Size: 4 Inch, DN100
Pressure: Class 150 LB, PN16
End Connection: RF
Operation: Electric Actuator

Product Range

Medium: Water, Liquid
Temperature: -20℃ to 150℃
Body Material: ASTM A216 WCB, A351 CF8, CF8M, A217 WC6, WC9, etc.
Connection: Flange, Welding
Position Type: Flow to open, Flow to close
Characteristic: Linear, Percentage, Quick open
Voltage: AC 220V, AC 380V, other custom voltages
Other: Soft seat for better seal performance

Electric control valves are used for controlling water pressure, water temperature, and water flow. The electric water control valve features a top guide structure, offering a compact design and an S-shaped streamlined fluid path. This design provides large flow capacity, small pressure differential loss, a wide adjustable range, and precise flow control. The spool guiding part of the electric water control valve has a large guide area, which ensures excellent anti-vibration performance. Additionally, the intelligent control module is built into the electric actuator, eliminating the need for an external positioner.

Technical Specification

Electric control valve Body type	straight through casting globe type
Spool type	non-balanced single seat plug type
Nominal size	DN25-DN300, 1-12 Inch
Nominal pressure	PN16-100, Class 150-600 LB
Connection (flange)	FF/RF/MF/RTJ
Welding	SW、BW
Flange dimension	According to to IEC 60534
Electric water control valve Bonnet type	Ⅰ: standard type (-20℃ to 230℃) Ⅱ: Radiator type: (-45℃ to high than 230℃ occasion) Ⅲ: Low temperature extended type (-196℃ to -45℃) Ⅳ: Bellow seal type Ⅴ: Warm insulation Jacket type
Packing	V type PFTE packing, flex. graphite packing, etc
Gasket	Metal graphite packing
Actuator	Electric: 3810L series smart actuator, PSL series actuator
