ASTM B148 C95800 Butterfly Valve, API 609 CAT B, 3 IN, CL150

Name: ASTM B148 C95800 Butterfly Valve, API 609 CAT B, 3 IN, CL150
SKU: KV-20241231-HPBV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

This High-Performance Butterfly Valve, made from ASTM B148 C95800 material, is designed to API 609 Category B standards. Featuring a double-offset structure, it comes in a 3-inch size with a Class 150 LB pressure rating and lug ends, providing durable and efficient bi-directional flow control for industrial applications.

Request a quote

Detail Information

Product Name: ASTM B148 C95800 High Performance Butterfly Valve
Features: Bi-directional Design, Blow-out Proof Shaft, Double Offset
Design Standard: API 609 Category B
Body Material: ASTM B148 C95800, Nickel Aluminium Bronze
Size: 3 Inch, DN80
Pressure: Class 150 LB, PN20
End Connection: Lug
Operation: Lever

The double offset high-performance butterfly valve in bronze is designed for versatility and durability, making it suitable for a wide range of applications. Its bi-directional flow design, along with a blow-out-proof shaft, ensures reliable performance under even the most challenging conditions. The valve is highly customizable, with a range of seat options available—soft seat, metal seat, or fire-safe seat—allowing for enhanced compatibility with specific customer requirements. This flexibility makes it ideal for diverse industries and environments. With its robust construction and customizable features, this valve provides an efficient and reliable solution for flow control across various industrial sectors.

Technical Specifications

» Design: Double Offset Type
» Size Range:
Class 150 LB: 2-48 Inch
Class 300 LB: 2-48 Inch
Class 600 LB: 2-24 Inch
» Pressure Rating: Class 150-600 LB, PN10-PN40, 10K-20K
» Standard: API 609 Category B
» Body Material: Aluminium Bronze (ASTM B148 C95800, C83600, B584 C84400, ASTM B62)
» Disc Material: Aluminium Bronze (ASTM B148 C95800, C83600, B584 C84400, ASTM B62)
» Shaft Material: MONEL K500
» Shutoff Rating: Class VI, Bubble Tight
» Certifications: API 607, PED
» Valve Seat Design: Unique Valve Seat Design with optional seating materials
» Optional Seatings: RTFE (Resilient)
» Operation Types: Handle, Worm Gear, Pneumatic, Electric
» Temperature Range:
Soft Seat: -29°C to 260°C
Metal Seat: -51°C to 550°C
Metal Seat (Cryogenic): -196°C to 121°C
Fire-Safe Seat: -51°C to 550°C
» End Connections: Wafer, Lug, RF Flange

Application Scope

» Chemical & Petrochemical: Liquefied Gas, Refrigeration
» Heavy Industrial: Power and Co-Generation Plants, Steel and Iron Works
» Commercial: Pulp and Paper Mills, Oil Refineries
» Marine & Shipbuilding: Hydrocarbon Processing, Gas Piping, Local Area Energy Supply
» Construction: Industrial and Marine Applications
