ASTM A182 F316 Ball Valves, ASME B16.34, 3PC, 1 Inch, CL2500

This ASTM A182 F316 Ball Valve features a rugged 3-piece forged stainless steel body for superior strength and corrosion resistance. Built to ASME B16.34 standards, it is designed for high-pressure applications with a 1 inch (DN25) size and pressure ratings of Class 2500 LB (PN420). The valve includes FNPT threaded ends and a manual lever for reliable on-off operation, making it ideal for demanding environments in chemical, petrochemical, and industrial process systems.

Product Name: Forged Steel ASTM A182 F316 Ball Valve, 3PC
Design Standard: ASME B16.34
Body Material: ASTM A182 F316
Size: 1 Inch, DN25
Pressure: Class 2500 LB, PN420
End Connection: FNPT
Operation: Lever
Medium: Water, Oil, Gas, etc
Temperature Range: -29°C to 150°C

Forged Steel Ball Valves are available in Two-Piece Split Body and Three-Piece Bolted Body configurations. The use of forged materials ensures superior strength and rigidity under maximum rated pressure, eliminating defects commonly found in cast body designs.
These valves are engineered with ample wall thickness and secured using high-strength tie bolts, allowing for stress resistance and convenient maintenance. Internals are precisely designed and carefully selected to ensure durability and dependable performance across diverse working conditions.

Technical Specifications

» Size Range: 1/2-2 Inch
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Body Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, and special alloys
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other options
» Seat Materials: PTFE, RPTFE, PEEK
» End Connections: SW (Socket Weld), FNPT (Female NPT), BW (Butt Weld)
» Design & Manufacture Standards: ASME B16.34, API 602
» Face-to-Face Dimensions: ANSI B16.10
» Flanged Connections: ANSI B16.5
» Butt Weld Ends: ANSI B16.5
» Threaded Ends: ASME B1.20.1
» Socket-Weld Ends: ASME B16.11
» Testing & Inspection: API 598, API 6D

Product Features

» Offered in One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body configurations
» Fully compliant with international standards such as API 6D, ASME B16.34, and BS 5351
» Includes standard safety features:

• Fire-Safe Design
• Anti-Static Device
• Blow-Out Proof Stem

» Compact, robust structure with low torque operation
» Suitable for various pressure classes and process conditions
