Aluminum Alloy Pinch Valve, 1/2-4 IN, Air Operated, Threaded

Name: Aluminum Alloy Pinch Valve, 1/2-4 IN, Air Operated, Threaded
SKU: KV-20250125-PV-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Aluminum Alloy Pinch Valve is designed for efficient flow control in compact systems. Available in sizes from 1/2 to 4 inches (DN15-DN100), it features a durable rubber sleeve that ensures a tight seal and effective regulation of flow. This air-operated valve is equipped with EN ISO 228 G and ANSI/ASME B1.20.1 NPT threaded connections, providing secure installation, ideal for controlling the flow of abrasive or viscous media.

Request a quote

Detail Information

Product Name: Aluminum Alloy Pinch Valve
Normal Size Range: 1/2-4 Inch (DN15-DN100)
Body Material: Aluminum Alloy
Thread Standard: EN ISO 228 G, ANSI/ASME B1.20.1 NPT
Operation: Air Operated
Temperature Range: -29 to 80 Degree C
Sleeve: Natural Rubber, Natural Rubber, EPDM

Our pinch valves are ideal for shut-off or control applications involving abrasive or corrosive slurries, powders, or granular substances. Our advanced flow control solutions are designed to meet even the most demanding customer specifications. KOSEN pinch valves enhance productivity by improving process efficiency and extending service intervals.

The valve design consists of three main components: the sleeve, the body, and the actuator. The sleeve is the only part in contact with the process medium. The construction and materials of all components can be tailored to suit a variety of process conditions. Our pinch valves ensure a 100% tight shut-off, even when solids accumulate on the sleeve wall. When compressed, any crystallized particles flake off the sleeve surface and are washed downstream, maintaining valve performance.
