Cost-Efficient Adult Diaper Machinery with Crusher System

Cost-Efficient Adult Diaper Machinery with Crusher System


Subject	Parameter
Overall size(L*W*H)	24M*4M*3.6M(For reference only)
Machine size(L*W*H)	22m*2.1m*3.3m,based on the product provided by  client
Design speed	300pcs/min
Stable speed	180pcs/min
Pass precentage	98%
Work efficiency	85%-90%
Power source	380V,50HZ,(3phase,4lines+ground wire)
Machine capacity	about 400KW
Air pressure	0.6-0.8Mpa
Machine weight	About 95T
Machine color	Customized


Configuration:

1. Frequecy motor/servo motor driving controlled by PLC with touch screen;
2. Raw materials auto unwinding with tension control and auto spliciing units;
3. Raw Materials web guiding units;
4. Single high speed cell mill;
5. Single drum former for continuous fluff core formation;
6. Single SAP applicator;
7. Laminatited core (fiber cotton with SAP) unwinding and feeding units (option);
8. Fluff core embossing and cutting units;
9. 3D floating core applicator (option);
10. ADL/Air-laid paper feeding & cutting units;
11. Elastic band unwinding and feeding unit;
12. 3D side leakage guard applicating unit;
13. Leg cuff applicating unit;
14. Elastic waistband cutting and applicating unit;
15. Backsheet lamination unit;
16. Side tapes cutting and applicating unit;
17. Frontal tape positioning and cutting unit;
18. Rotary die cutting unit;
19. Final cutting unit;
20. Stacker (option);
21. Packing machine (option);
22. Dust collection filter system (option)



Main Product:

1. Baby diaper Production Line
2. Adult diaper Production Line
3. Sanitary Napkin & Panty Liner Production Line
4. Menstruation Panty Production Line
5. Under Pad Production Line
6. Disposable Breast Pad Production Line
